Amana 51202 Solid Carbide Panel Pilot Bevel Trim Router Bit
Trimming Router Bits: Bevel Trim Router Bits, Solid Carbide: 7° x 1/4″ Dia x 1/4″ x 1/4″ Shank
The ideal laminate trimming bit for high-volume production. Solid carbide and integral pilot (no bearing to maintain) extend life of bit, slim configuration reduces vibration. Suitable for routers and trimmers.
Standard Equipment:
51200 Solid Carbide Panel Pilot Flush Trim Router Bit
Specifications:
Type: 7° Bevel
Diameter (D): 1/4″
Cutting Height (B): 1/4″
Shank (d): 1/4″
Overall Length (L): 1-1/2″
Flutes: 1
Features:
High quality long lasting European sub-micrograin & micrograin carbide
Thick carbide for multiple resharpenings
Different carbide grades for different materials
Silver induction brazing for maximum carbide bonding strength
Produced according to Holz-BG German standards for safety and quality
Centerless ground shank for exact fit
Multi axis grinding
Bodies manufactured in single clamping for superior balance, symmetry, precision and centricity
Use of only solid bar stock steel (brazed bits)
Shanks laser etched with size, maximum RPM ratings and clamping depth
