Amana 54532 Traditional Vertical Raised Panel Router Bit
Door Making Router Bits: Vertical Raised Panel Router Bits, Carbide Tipped: 15° x 1-1/8″ Dia x 1-5/8″ x 1/2″ Shank
Raised panels with a low-horsepower, fixed speed router using these VERTICAL raised panel bits. You must do the work on a router table, with the work on edge, braced against the fence. Arched or curved shapes (i.e.: “cathedral” door panels) cannot be routed. To prolong tool life and get the best cut finish, several passes are recommended.
Standard Equipment:
54532 Traditional Vertical Raised Panel Router Bit
Specifications:
Diameter (D): 1-1/8″
D1: 19/32″
Angle (a°): 15°
Cutting Height (B): 1-5/8″
Shank (d): 1/2″
Overall Length (L): 3-1/8″
Flutes: 2
Features:
High quality long lasting European sub-micrograin & micrograin carbide
Thick carbide for multiple resharpenings
Different carbide grades for different materials
Silver induction brazing for maximum carbide bonding strength
Produced according to Holz-BG German standards for safety and quality
Centerless ground shank for exact fit
Multi axis grinding
Bodies manufactured in single clamping for superior balance, symmetry, precision and centricity
Use of only solid bar stock steel (brazed bits)
Shanks laser etched with size, maximum RPM ratings and clamping depth
