Description

Bosch RH745 1-3/4″ SDS-Max Rotary Hammer

The Bosch RH745 1-3/4″ SDS-max rotary hammer features best in class drilling and chiseling performance with 7.6 ft. lbs. impact energy (EPTA). The hammer features 2 modes of operation: rotary hammer or hammer-only and a variable speed dial for controlled drilling and chiseling applications. The tool also features the vario-lock function which allows the chisel to be rotated into 12 different positions to optimize the working angle when used in hammer only mode.

Standard Equipment:

• RH745 Rotary Hammer
• 360° Auxiliary Handle
• Carrying Case

Optional Accessories:

• SDS-Max Drilling Accessories
• SDS-Max Demolition Accessories

Specifications:

• Rating: 120V AC
• Amperage: 13.5
• No-load RPM: 150 – 305
• No-load BPM: 1,380 – 2,750
• Impact Energy 7.6 ft-lbs
• Maximum Capacities…
  Concrete Bit: 1-3/4″
  Concrete Core Bit: 6″
  Concrete Thru-Hole Bit: 3-1/8″
• Optimal Concrete Range:
  5/8″ – 1-9/16″
• Tool Holder: SDS-Max
• Length: 21.0″
• Width: 4.0″
• Height: 10.5″
• Weight: 18.5 lbs

Features:

• SDS-max bit system provides tool-free bit changes with automatic bit locking, dust protection and maximum impact energy transfer rate.
• Combination dual mode selector – 2 modes of operation: rotary hammer and hammer only mode.
• Variable speed dial provides accurate bit starting and controlled chipping applications.
• Turbo™ Power feature delivers 10% more power in hammer only mode.
• Service Minder light indicates when preventative maintenance is required.
• Vario-Lock positioning rotates and locks chisel into 12 different positions to optimize working angle.
• 360° Auxiliary handle provides a wide range of movement along with operator comfort.
• Soft grip rear handle absorbs shock and vibration for operator comfort and less fatigue.
